Cryostat Microtome CRM-01
Labotemp Cryostat Microtome
Labotemp Cryostat Microtome
Labotemp Cryostat Microtome
Labotemp Cryostat Microtome
Labotemp Cryostat Microtome

Cryostat Microtome CRM-01

Labotemp Cryostat Microtome CRM-01, also known as a freezing microtome or cryotome, is a specialized microtome machine used in microtomy in histopathology for rapid frozen tissue sectioning. Designed for precise cryostat sectioning of fresh and frozen tissue, the CRM-01 supports accurate intraoperative diagnosis and urgent pathology workflows. This advanced cryostat microtome produces uniform thin sections with an adjustable cut thickness from 0.5 µm to 100 µm, enabling reliable microtomy and consistent sample preparation for laboratory microscopy.

The fully enclosed cryogenic chamber operates from 0°C to –60°C, providing stable freezing conditions for dependable performance. Controlled specimen movement with 65 mm vertical stroke, 22 mm horizontal stroke, and 100 µm specimen retraction improves section quality and protects the blade. A rigid microtome blade holder supports disposable microtome blades and microtome knives, maintaining a clean cutting edge for reproducible sections.

Why choose Labotemp Cryostat Microtome CRM-01?

✓ Wide thickness range: Accurate frozen sectioning from 0.5–100 µm
✓ Stable cryostat sectioning: Controlled freezing down to –60°C
✓ Safe laboratory operation: Integrated UV disinfection and enclosed chamber

$16630
Datasheet
General Specifications
Section Thickness Range 0.5–100 µm adjustable
Section Thickness Setting 0.5–2 µm in 0.5 µm increment
2–5 µm in 0.5 µm increment
5–20 µm in 1 µm increment
20–50 µm in 2 µm increment
50–100 µm in 5 µm increment
Trimming Thickness Range 1–600 µm adjustable
0–5 µm in 5 µm increment
50–100 µm in 10 µm increment
100–600 µm in 50 µm increment
Tissue Retraction Function 0–100 µm adjustable in 2 µm increment
Pellet Cooling Working Time 15 minutes
Freezing Chamber Temperature Range −10°C to −40°C
Speed of Fast Forward and Backward 0.9 m/s, 0.45 m/s
Specimen Head Minimum Temperature 0°C to −60°C
Maximum Specimen Size 55 × 60 mm
Freeze Shelf Minimum Temperature 0°C to −55°C
Lowest Temperature of Peltier Units on Freezing Shelf −60°C
Specimen Vertical Stroke 65 mm
Specimen Horizontal Stroke 22 mm
Power 1500 W
Power Supply AC 220 V / 50 Hz
Disinfection Method UV
Construction & Operation
Chamber Design Fully enclosed cryogenic chamber
Specimen Retraction Adjustable, up to 100 µm
Specimen Movement Controlled vertical and horizontal movement
Handwheel 16-position handwheel
Compressor Fanless compressor (Secop)
Blade Compatibility Disposable microtome blades and microtome knives
Product Dimensions
Dimensions (W × D × H) 700 × 780 × 1650 mm
Net Weight 210Kg
Gross Weight 225Kg
Package Size(W × D × H) 930 × 870 × 1450 mm
  • ➤ Up to 100 µm retraction
  • ➤ Adjustable 0.5–100 µm thickness supports diverse frozen tissue applications.
  • ➤ Controlled freezing conditions support consistent frozen-section preparation.
  • ➤ Freezing shelf temperature can reach as low as −60°C.
  • ➤ Helps maintain controlled cryogenic conditions during sectioning.
  • ➤ Up to 100 µm retraction helps protect the blade and improve section quality.
  • ➤ Provides controlled specimen movement and safer manual operation.
  • ➤ Supports multiple specimens for efficient frozen-section workflows.
  • ➤ 0.9 m/s and 0.45 m/s forward/backward speeds support efficient positioning.
  • ➤ Integrated UV system supports hygienic chamber operation.
  • ➤ Supports stable cooling performance with reduced mechanical disturbance.
  • ➤ 65 mm vertical and 22 mm horizontal strokes provide controlled positioning.
  • ➤ Supports disposable blades and microtome knives for reliable sectioning.
  • ➤ Accommodates specimens up to 55 × 60 mm.
  • ➤ Cryogenic chamber and specimen-head cooling support reproducible frozen sectioning.
  • Intraoperative Diagnosis
    Enables rapid preparation of frozen tissue sections when immediate pathological evaluation is required
  • Histopathology Laboratories
    Supports frozen tissue sectioning for microscopic examination and pathology workflows
  • Pathology & Diagnostic Laboratories
    Suitable for rapid tissue preparation during diagnostic procedures
  • Oncology Departments
    Supports intraoperative assessment of tumor margins and other fresh tissue specimens
  • Surgical Departments
    Provides rapid frozen-section preparation to assist time-sensitive surgical decisions
  • Research Laboratories
    Useful for cryogenic tissue preparation and research involving fresh or frozen biological specimens
